Gain: 5 dBi
VSWR: ≤1.5
HPBWH: 360°
HPBWv: 80°±20°
Polarization: Vertical
.png)
.jpg)
.jpg)
.jpg)
|
Model |
XJS-SP-O0642-5V |
|
|
Frequency Range |
698-4200 MHz |
|
|
Gain |
5 dBi |
|
|
Horizontal Beamwidth(3dB) |
360° |
|
|
Vertical Beamwidth(3dB) |
60°±20° |
|
|
Polarization |
Vertical |
|
|
VSWR |
≤ 1.5 |
|
|
Impedance |
50 Ω |
|
|
Connector |
N-Female |
|
|
Max. Power |
100 W |
|
|
Lightning Protection |
DC Ground |
|
|
Dimension |
φ60*220 mm |
|
|
Weight |
≈0.4 kg |
|
|
Operating Temperature |
-40℃～+60℃ |
|
|
Wind Loading |
170 km/h |
|
|
Mounting |
Pole Mount |
|
