Model |
TDS-4865-21x4 |
|
Frequency Range |
4800 - 6500 MHz |
|
Gain |
21 dBi |
|
Horizontal Beamwidth(3dB) |
45° |
|
Vertical Beamwidth(3dB) |
8° |
|
Polarization |
± 45° |
|
F/B Ratio |
≥ 45 dB |
|
VSWR |
≤ 1.8 |
|
Impedance |
50 Ω |
|
Connector |
4 x SMA or 4 x N-Female |
|
Max. Power |
50 W |
|
Lightning Protection |
DC Ground |
|
Dimension |
750 x 142 x 64 mm |
|
Weight |
5 kg |
|
Operating Temperature |
-35℃～+50℃ |
|
Wind Loading |
126 m/s |
|
Mounting |
Pole Mount |
